Description

The compact (3/4 size) SC15 PRISMA is a full-featured pre-amplifier and network player featuring WiSA wireless speaker connection technology, high resolution DAC stage incl USB up to 768kHz/32bit and DSD256, as well as complete digital media access and system management through Prisma connectivity and control technology.

Features:

  • DAC:
    Inputs: 3 x TOSLINK (192kHz/24 bit); 1 x RCA (192k/24 bit); 1 x 3,5 mini-plug (192kHz/24 bit); 1xUSB-B (up to PCM 768kHz/32 bit; DSD 256/11.2MHz)
    Output: 1 x RCA (analogue in = 48kHz out; digital in = pass-through)
    Frequency Response: 20Hz – 20kHz +0.1/-0.6dB
    Signal to Noise: >90dB
  • PRISMA:
    Audio Formats: WAV, LPCM, AIFF, FLAC, ALAC, MP3, MP4 (AAC), WMA, OGG, DSD
    Wired Inputs: USB-A, LAN (up to 192kHz/24 bit; DSD 128/5.6MHz)
    Wireless Inputs: Bluetooth®, AirPlay, Spotify Connect, Chromecast built-in
    WLAN: IEEE 802.11 a/b/g/n/ac compliant; 2.4/5g Hz b, g, n mode
    WiSA: 24/48-96kHz high-resolution wireless speaker connection
  • GENERAL:
    Control: C25 remote control; RS232; IR in/out; Trigger out
    Power Consumption: Standby 0.5W; Operate 25W
  • Dimensions (w x d x h): 350 x 329 x 73 mm with knobs and connectors
  • Weight: 6.4 kg
  • Colour Options: Black or Titanium
