Description
The award-winning flagship S7t design adapted for THX Dominus Certified in-wall applications.
Specifications:
- Enclosure Alignment: 4-way acoustic suspension
- Driver complement: DPC Array: 28mm Beryllium, 28mm (2) Textreme TPCD; Woofers: 180mm (4) Textreme TPCD
- Sensitivity: 91.9dB / 2.83V / 1.0m
- Impedance: 4Ω nominal / 3.4Ω min
- Response Linearity: 80 – 20kHz +/-1.5dB window
- Frequency Response (-10dB): 45 – 37kHz
- Typical In Room bass extension: 37Hz
- Dimensions (HxWxD): 1036.6 x 298.6 x 111.2mm
- Mounting Dimensions (HxWxD): 996 x 257 x 101.7mm
- Weight: 26.4 kg
- Recommended Amplifier Power: 100 – 600W RMS
- SPL capability @1m (100-20kHz): 119.7dB peak; 117.0dB peak <3% 2nd, 3rd Harmonics
- Certification: THX Dominus
