Description

Two-channel high fidelity speaker with the versatility to be used in multi-channel systems. Featuring DPC-Array of three 26mm silk domes and twin 165mm HFP woofers, which can be aligned as bass reflex or acoustic suspension depending on specific tastes. THX Dominus certified.

Features:

  • Enclosure Alignment: 4-way bass reflex / acoustic suspension
  • Driver complement: DPC-Array: 26mm(3) Silk dome, woofers: 165mm (4) HPF diaphragms
  • Sensitivity: 90.0dB/2.83V/1.0m
  • Impedance: 4Ω nominal/3.1Ω min
  • Response Linearity 80 – 20kHz +/-1.5dB
  • Frequency Response (-10dB): Bass reflex: 27 – 32kHz; Acoustic suspension: 38 – 32kHz
  • Typical In Room bass extension: bass reflex: 19Hz; acoustic suspension: 30Hz
  • Dimensions (HxWxD): 1268 x 230 x 350mm
  • Weight: 48.0 kg
  • Recommended Amplifier Power: 100 – 400W RMS
  • SPL capability @1m (100-20kHz): 116.0dB peak <3% – 2nd, 3rd Harmonics
  • Certification: THX Dominus; THX Ultra
  • Finishes: high gloss black

Review Links:

Perlisten Audio R7t, Hi Fi News August 2022, Outstanding SEE REVIEWS AND DOWNLOADS
