Description

Designed to be mounted on optional stand, or wall mounted using dedicated tilt/swivel bracket. Featuring DPC-Array of three 26mm silk domes and twin 165mm HFP woofers. THX Dominus certified.

Features:

  • Enclosure Alignment: 3-way acoustic suspension
  • Driver compliment: DPC-Array: 26mm (3) Silk dome, woofers: 165mm(2) HPF diaphragms
  • Sensitivity: 88.6dB/2.83V/1.0m
  • Impedance: 4Ω nominal / 3.4Ω min
  • Response Linearity: 80 – 20kHz +/-1.5dB
  • Frequency Response (-10dB): 49 – 32kHz
  • Typical In Room bass extension: 44Hz
  • Dimensions (HxWxD): 240 x 550 x 270mm
  • Weight: 15.0 kg
  • Recommended Amplifier Power: 100 – 250W RMS
  • SPL capability @1m (100-20kHz): 112.6dB peak <3% – 2nd, 3rd Harmonics
  • Certification: THX Dominus, THX Ultra
  • Finishes: High Gloss Black
