Description

Designed to be mounted on optional stand, or wall mounted using dedicated tilt/swivel bracket. Featuring DPC-Array of three 26mm silk domes and single 165mm HFP woofer. THX Ultra certified.

Features:

  • Enclosure Alignment: 3-way acoustic suspension
  • Driver complement: DPC-Array: 26mm (3) Silk dome, woofers: 165mm HPF diaphragm
  • Sensitivity: 84.6dB/2.83V/1.0m
  • Impedance: 4Ω nominal / 3.8Ω min
  • Response Linearity: 80 – 20kHz +/-1.5dB
  • Frequency Response (-10dB): 45 – 32kHz
  • Typical In Room bass extension: 38Hz
  • Dimensions (HxWxD): 382 x 230 x 336mm
  • Weight: 9.5 kg
  • Recommended Amplifier Power: 50 – 200W RMS
  • SPL capability @1m (100-20kHz): 107.6dB peak <3% – 2nd, 3rd Harmonics
  • Certification: THX Ultra
  • Finishes High Gloss Black
