Description

Variations:

PASSIVE ON WALL, 121 dB (Cont.) / 133 dB (Peak), 95 – 20 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 390 x 615 x 175, finish: Structural paint black, Recommended ASCENDO electronics: AIA2-2704, AIA4-2404, AIA4-6004, AIA8-6004

PRO PASSIVE ON WALL, 123 dB (Cont.) / 135 dB (Peak), 75 – 21 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 444 x 668 x 200, finish: Structural paint black, Recommended ASCENDO electronics: AIA2-2704, AIA2-6004, AIA4-2404, AIA4-6004, AIA8-6004, AIA ULN2-2604 D

PRO ACTIVE EXT ON WALL, 120 dB (Cont.) / 130 dB (Peak), 55 – 21 kHz -3dB, Dimensions W x H x D mm (Without Grille): 444 x 668 x 200, finish: Structural paint black, 2Ch DSP + 2Ch Amplifier are required, Recommended ASCENDO electronics: DSP ULN2-2604 D

PRO PASSIVE WEDGE, 123 dB (Cont.) / 135 dB (Peak), 75 – 21 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 500 x 312 x 450 (Vertical), finish: Structural paint black, Recommended ASCENDO electronics: AIA2-2704, AIA2-6004, AIA4-2404, AIA4-6004, AIA8-6004, AIA ULN3-6004

PRO ACTIVE EXT WEDGE, 120 dB (Cont.) / 130 dB (Peak), 55 – 21 kHz -3dB, Dimensions W x H x D mm (Without Grille): 500 x 312 x 450 (Vertical), finish: Structural paint black, 2Ch DSP + 2Ch Amplifier are required, Recommended ASCENDO electronics: DSP ULN2-2604 D

PRO PASSIVE ON WALL, BERYILLIUM DOME, 123 dB (Cont.) / 135 dB (Peak), 75- 21 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 444 x 668 x 200, finish: Structural paint black, Recommended ASCENDO electronics: AIA2-2704, AIA2-6004, AIA4-2404, AIA4-6004, AIA8-6004, AIA ULN3-6004

PRO ACTIVE EXT ON WALL, BERYILLIUM DOME, 120 dB (Cont.) / 130 dB (Peak), 55 – 21 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 444 x 668 x 200, finish: Structural paint black, 2Ch DSP + 2Ch Amplifier are required, Recommended ASCENDO electronics: DSP ULN2-2604 D

PRO PASSIVE WEDGE, BERYILLIUM DOME, 123 dB (Cont.) / 135 dB (Peak), 75 – 21 kHz -3 dB, Dimensions W x H x D mm (Without Grille): 500 x 312 x 450 (Vertical), finish: Structural paint black, Recommended ASCENDO electronics: AIA2-2704, AIA2-6004, AIA4-2404, AIA4-6004, AIA8-6004, AIA ULN3-6004

PRO ACTIVE EXT WEDGE, BERYILLIUM DOME, 120 dB (Cont.) / 130 dB (Peak), 55 – 21 kHz -3dB, Dimensions W x H x D mm (Without Grille): 500 x 312 x 450 (Vertical), finish: Structural paint black, 2Ch DSP + 2Ch Amplifier are required, Recommended ASCENDO electronics: DSP ULN2-2604 D

For more detailed specifications, please see datasheets in DOWNLOADS
